Carrier frequency: UHF610 ~ 920MHz
■ Number of channels: dual-channel
■ Modulation Mode: FM
■ Oscillation mode: PLL phase-locked frequency synthesizer
■ Band width: 30MHz
■ Sensitivity: The degree of offset is equal to 25KHz, Input 6dBv, S/N >60dB
■ Maximum deviation: ±45KHz
■ Comprehensive S/N ratio: >105dB
■ Comprehensive T.H.D: <0.7% @ 1KHz
■ Frequency response: 45Hz ~ 18KHz ±3dB
■ Supply: DC 12V ~ 16V 10W
■ Output connector: XLR parallel and 6.3 parallel socket
■ Effective working distance: 100 metersHandheld Transmitter:
■ Carrier frequency: UHF610 ~ 920MHz
■ Oscillation mode: PLL phase-locked frequency synthesizer
■ Band width: 120MHz
■ Harmonic radiation: <-65dBm
■ Maximum deviation: ±45KHz
■ Frequency response: 45Hz ~ 18KHz±3dB
■ capsule: Dynamic
■ RF power output: 15MW
■ Battery: AA x 2
■ Current consumption: <90mA
■ Continuous working time: 12 hoursBodypack Transmitter:
■ Carrier frequency: UHF610 ~ 920MHz
■ Oscillation mode: PLL phase-locked frequency synthesizer
■ Band width: 120MHz
■ Harmonic radiation: <-65dBm
■ Maximum deviation: ±45KHz
■ Frequency response: 45Hz ~ 18KHz ± 3dB
■ capsule: Condenser
■ RF power output: 15MW
■ Battery: AA x 1
■ Current consumption: <90mA
■ Continuous working time: 8 hours
